How to: Sprockets and chains



SPROCKET (CHAINWHEEL)

Old BMX bikes were equipped with 48T (teeth) sprockets, however this is not a standard nowadays. Most common sprocket size today is 25T or 28T with 23,7mm bore. There are two basic sprocket types - bolt drive and spline drive. Bolt drive sprocket is attached to the crank arm with the bolt. Spline drive sprocket is pulled straight onto the 48-spline spindle and usually lasts longer. However, if there's more than one tightening hole on the bolt drive sprocket, then the lifespan is pretty much the same.

"T" = number of teeth (25T, 28T, 30T)

See the picture above from the left: bolt drive sprocket with only one attaching hole, another one with 3 holes, sprocket with guard.



Spline Drive Sprocket (SD)
SDS features a hardenned steel insert that is designed either for 19mm or 22mm spindle and it's pulled straight onto the 48-spline spindle. Spline drive sprocket doesn't have any tightening bolt.




How do I know which sprocket will work with my bike?

There are two things to consider when purchasing a new chain wheel. The width of the teeth on the chain wheel and the bore of the spindle hole determine compatibility. Chain wheels with 3/32 teeth will work with all size chains. Chain wheels with 1/8 inch teeth will only work with 1/8 an 3/16 chains. A chain wheel with a 15/16 inch bore will work with all cranks. All other bore sizes are limited in what cranks can be used. An adapter may be required to adapt a certain chain wheel to a certain crank

CHAIN

Chain is a very important part that has to be maintained in perfect condition. There are two basic chain types,

Full link: Low weight and more affordable price, however you got less options in setting up your back wheel position.
Half link: Recently most used chain mainly because it has always been a struggle to set the ideal chain length with full link.

Two most used chain sizes in BMX are:
3/32" - RACING
1/8"  - FREESTYLE

What type of chain you should use for 8T drivers?
It is recommended to use the half-link chain. The one that proved to be very strong and durable is The Shadow Conpiracy Interlock V2.





See the picture from the left: basic full link chain, silver half-link chain, blue half link chain TSC Interlock V2, wider chain tool for half-link chains.

Popular GEAR RATIO

Most of a recent freestyle BMX rear hubs are equipped with the 9T driver that is usually combined with either 25T or 28T sprocket, although there are still a lot of bikes around from the previous period of BMX when bikes were heavier and components bigger. Those of you riding an old horse, have a look at the chart bellow to see the ideal gear ratio.

22T - 8T
23T - 8T
25T - 9T
28T - 10T
30T - 11T
33T - 12T
36T - 13T
39T - 14T
41T - 15T
44T - 16T


How do I determine what gear ratio is best for me?

Like many aspects of bike set-up, gear ratio is a matter of personal preference. Increasing the number of teeth on the front sprocket or decreasing the number of teeth on the rear sprocket will result in a higher gear ratio. This will make the bike hard to pedal on take off but will allow a higher overall speed. Decreasing the number of teeth on the front sprocket or increasing the number of teeth on the rear sprocket will result in a lower gear ratio. This will make the bike easier to pedal on take off and result in a lower top speed. It is best to use your current gear combination as a starting point then determine what you are trying to achieve.
